Silicone Foam

Silicone Foam Thermal Interface Material

Made from liquid silicone cured under heat, offers high compressibility and superior resilience. Its eco-friendly properties and UL94 V-0 flame retardant rating make it an ideal choice for various applications, including battery pack liquid cooling support, lighting equipment sealing, and electrical control cabinet protection.

Features :

• High compressibility and excellent resilience for effective shock absorption, providing robust protection for devices.
• Available in a wide range of thicknesses, with uniform foaming that makes it easy to cut and process.
• Low stress relaxation properties help reduce maintenance costs associated with material failure.
• Ultra-soft characteristics offer protective seals with low closure forces to accommodate tolerances.
• Flame resistance rated at UL94 V-0, enhancing safety standards.
• Resistant to UV, ozone, and extreme temperatures, ensuring long-term stability.

Applications :

• Electric Vehicles (EV)
• Battery packs
• Lighting and HVAC equipment
• Electrical control cabinets
• Electrical components
• Insulation systems

Model	Density, kg/m3	Thickness, mm	Compression Set, at 50%, 100℃	Elongation	Flame Rating, UL 94	Operating Temp., ℃
JSSA-700-200	200	1.6~20.0	< 5%	60%	V-0, HF-1	-55~220
JSSA-700-260	260	1.2~20.0	< 5%	70%	V-0, HF-1	-55~220
JSSA-700-300	300	1.2~20.0	< 5%	60%	V-0, HF-1	-55~220
JSSA-700-350	350	0.6~20.0	< 5%	90%	V-0, HF-1	-55~220
JSSA-700-400	400	1.0~20.0	< 5%	80%	V-0, HF-1	-55~220
