JSY07532

Bracket DC Fans Fans & Blowers

Framesize: 75x75x32 mm

  • MOTOR : DC brushless motor
  • FRAME : PBT (94V-0) ; IMPELLER : PBT(94V-0)
  • OPERATING TEMP.: -10°C~70°C
  • STORAGE TEMP.: -40°C~70°C
  • WEIGHT : 92.0g
  • SAFETY : UL / CUL / CE
 Download Brochure
Decorative banner image for: JSY07532

JSY07532 Products List

Model No.
Bearing Type
Voltage (DC)
Current (A)
Power (W)
Speed (RPM)
Airflow (CFM)
Pressure (InAq)
Noise (dB/A)
JSY0753212LB1A01 Two Ball 12 0.76 9.12 3500 19.10 0.625 45.0
JSY0753212LS1A01 SLEEVE 12 0.76 9.12 3500 19.10 0.625 45.0
JSY0753212MB1A01 Two Ball 12 0.98 11.76 4500 24.54 0.805 49.0
JSY0753212MS1A01 SLEEVE 12 0.98 11.76 4500 24.54 0.805 49.0
JSY0753212HB1A01 Two Ball 12 1.20 14.40 5500 30.00 0.984 56.8
JSY0753212HS1A01 SLEEVE 12 1.20 14.40 5500 30.00 0.984 56.8
JSY0753224LB1A01 Two Ball 24 0.37 8.88 3500 19.10 0.625 45.0
JSY0753224LS1A01 SLEEVE 24 0.37 8.88 3500 19.10 0.625 45.0
JSY0753224MB1A01 Two Ball 24 0.47 11.28 4500 24.54 0.805 49.0
JSY0753224MS1A01 SLEEVE 24 0.47 11.28 4500 24.54 0.805 49.0
JSY0753224HB1A01 Two Ball 24 0.58 13.92 5500 30.00 0.984 56.8
JSY0753224HS1A01 SLEEVE 24 0.58 13.92 5500 30.00 0.984 56.8
JSY0753248LB1A01 Two Ball 48 0.19 9.12 3500 19.10 0.625 45.0
JSY0753248LS1A01 SLEEVE 48 0.19 9.12 3500 19.10 0.625 45.0
JSY0753248MB1A01 Two Ball 48 0.25 12.00 4500 24.54 0.805 49.0
JSY0753248MS1A01 SLEEVE 48 0.25 12.00 4500 24.54 0.805 49.0
JSY0753248HB1A01 Two Ball 48 0.30 14.40 5500 30.00 0.984 56.8
JSY0753248HS1A01 SLEEVE 48 0.30 14.40 5500 30.00 0.984 56.8
